Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-75S
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation guidelines:
Maximum side load capacity 35N. Use locknuts (included) for stroke adjustment.
Lubricate with ISO VG32 turbine oil during maintenance. Allow 5mm clearance
around adjustment screws for tool access.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-75S Specifications
- Full model code: ACEJ50X100-75S
- Series range: ACEJ50~63 (50mm/63mm bore sizes)
- Bore size: 50mm (±0.5mm manufacturing tolerance)
- Stroke: 100mm (adjustable stroke mechanism)
- Operating pressure: 0.1~0.9 MPa (14.5~130.5 PSI)
- Cushioning type: Adjustable air cushion (dual-side)
- Mounting style: Standard square body with front flange
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston speed: 50~700 mm/s (lubricated condition)
- Ambient temperature: -20℃ to 80℃ (NBR seals)
- Tube material: Anodized aluminum alloy (6063-T5)
- Rod material: Chrome-plated steel (S45C)
- Seal type: Multi-lip NBR seals with wear indicator
- Weight: 1.25kg (excluding accessories)
- Dimensions: 154mm(L) × 50mm(W) × 50mm(H)
- ISO standard: 6432 (compact cylinder specifications)
- Repeat accuracy: ±0.5mm (with cushion adjustment)
Ultra-compact profile cylinder with integrated stroke adjustment mechanism, featuring dual-position locking screws for precise stroke control. The optimized flow path design reduces air consumption by 18% compared to previous models. Corrosion-resistant construction with IP54 protection rating enables operation in humid environments.
Typical Applications:
- Precision clamping in CNC machine tool changers
- Vertical lifting mechanisms in semiconductor handlers
- Variable position stops in packaging conveyors
- Automated test equipment positioning stages
- Medical device assembly actuators
Installation guidelines:
Maximum side load capacity 35N. Use locknuts (included) for stroke adjustment.
Lubricate with ISO VG32 turbine oil during maintenance. Allow 5mm clearance
around adjustment screws for tool access.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-75S |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
