Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-75SB
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-75SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-75SB Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Adjustable Compact Series
- Model Code Breakdown: ACEJ50X100-75SB
- 50: Bore size (50mm)
- 100: Stroke length (100mm)
- 75: Cushion adjustment range (±7.5mm)
- SB: Basic switch bracket (magnetic switch not included)
- Bore Size: Ø50mm
- Stroke: 100mm (adjustable ±7.5mm via cushion screws)
- Operating Pressure: 0.05-1.0 MPa
- Mounting Type: Standard basic mounting (NF1 pattern)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port Size: 1/4 NPT (G1/4 optional)
- Ambient Temperature: -20℃ to 80℃
- Piston Material: Extruded aluminum alloy barrel
- Rod Material: Stainless steel (SUS304)
- Seals: NBR standard (FKM available for high-temp)
- Weight: 1.8kg (excluding accessories)
- Dimensions:
- Overall Length: 198mm (at mid-stroke)
- Width: 66mm (mounting face to rear)
- Height: 50mm (barrel diameter)
This space-saving cylinder features dual adjustable air cushions for precise stroke-end control, with a unique anti-rotation guide design ensuring stable linear motion. The anodized aluminum construction provides corrosion resistance while maintaining lightweight properties. Built-in magnetizable piston enables sensor mounting for position feedback.
Ideal Applications:
- High-speed pick-and-place systems in electronics assembly
- Precision clamping fixtures for CNC machining centers
- Compact actuator for packaging machine diverters
- Automated door mechanisms in cleanroom environments
- Material handling robots with space constraints
Installation Tips:
- Align cylinder axis within 0.2mm angular misalignment tolerance
- Use locknuts (not included) for vibration-prone applications
- Lubricate with ISO VG32 turbine oil for initial operation
- Allow 15mm clearance for magnetic switch installation
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-75SB |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
