Airtac ACPJ Adjustable Compact Cylinder ACPJ12X10-10
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X10-10 Technical Details
- Model Code: ACPJ12X10-10
- Type: Single-acting spring return (adjustable stroke)
- Bore size: 12mm (±0.2mm tolerance)
- Stroke: 10mm (field-adjustable ±1mm)
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable air cushion (end-of-stroke)
- Mounting: Side mounting holes (M4) + optional foot bracket
- Temperature range: -10℃ to 80℃ (NBR seals)
- Piston material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Protection class: IP54 (standard wiper seal)
- Weight: 0.28kg (bare cylinder), 0.35kg with accessories
- Dimensions: 135mm(L) × 24mm(W) × 25mm(H) (retracted position)
Ultra-compact profile cylinder with unique stroke adjustment mechanism (external screw-type). Features dual-position sensing slots for magnetic switch installation (sensors not included). The zinc alloy end caps include integrated shock absorbers with 180° adjustable exhaust flow control. Rated for 5,000km service life at 0.5MPa.
- PCB handling robots with tight space constraints
- Medical device actuator assemblies requiring precise stroke control
- Packaging machine gate positioning systems
- Semiconductor wafer clamping mechanisms
- Automated test equipment sample positioning
Operation tip:
For optimal performance, lubricate with ISO VG32 turbine oil through air line
monthly. Max lateral load: 2.5N. Stroke adjustment requires 2mm hex key (not included).
Avoid mounting in vertical downward orientation without guide rails.
| Property | Property Value |
|---|---|
| sku | ACPJ12X10-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
