Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-100S
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ12X100-100S Adjustable Compact Cylinder Specifications
- Model: ACPJ12X100-100S
- Type: Double-acting adjustable compact cylinder
- Bore size: 12mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Front flange & rear pivot bracket
- Port size: M5x0.8 (standard), G1/8 optional
- Piston rod thread: M6x1
- Material: Aluminum alloy body, NBR seals
- Protection rating: IP40
- Weight: 0.35kg (excluding accessories)
- Dimensions: 180mm(L) × 40mm(W) × 40mm(H) (max extended length)
- Piston speed: 50–800mm/s
- Lubrication: Pre-lubricated (optional oil-free operation)
Ultra-compact cylinder with micro-adjustment capability (±0.5mm stroke precision) through integrated locknut mechanism. Features chrome-plated piston rod for wear resistance and anti-corrosion treatment for harsh environments. The 100S variant includes shock-absorbing pads and position detection slots for sensor mounting.
- Precision clamping in CNC tool changers
- Valve actuation in pharmaceutical dispensing systems
- Paper feed mechanisms in high-speed printers
- Position adjustment in semiconductor wafer handling
- Packaging machine stopper controls
Installation notes:
- Align piston rod axis within 0.2mm perpendicular tolerance
- Use flexible couplings for lateral force absorption
- Adjust cushion screws gradually (1/4 turns) for optimal deceleration
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-100S |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
