Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-20S
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ12X100-20S Adjustable Compact Cylinder Specifications
- Model: ACPJ12X100-20S
- Type: Double-acting adjustable cushion cylinder
- Bore size: Ø12mm
- Stroke: 100mm (adjustable stroke range: ±0.5mm)
- Operating pressure: 0.05–1.0 MPa
- Medium: Dry air (non-lubricated or oil mist lubricated)
- Cushioning: Adjustable rubber buffers at both ends
- Mounting type: Basic foot mounting (MF1 style)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel (SUS304)
- Seal material: Polyurethane (NBR optional)
- Temperature range: -10℃ to 80℃ (no freeze)
- Protection rating: IP54
- Weight: 0.82kg ±2%
- Dimensions: 156mm(L) × 34mm(W) × 34mm(H)
Ultra-slim cylinder with precision stroke adjustment capability, featuring dual shock absorption control via rotary cushion locks. Magnetic version available (add "-M" suffix). Ideal for high-cycle applications requiring mid-stroke positioning accuracy. Includes built-in auto-alignment mechanism for reduced side load.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Semiconductor wafer handling arms
- Textile machinery thread tensioners
- 3D printer automatic bed leveling
Installation note:
Use C-shaped wrenches (included) for cushion adjustment. Lubricate rod weekly with ISO VG32 turbine oil.
Maximum lateral load: 3.5N at full extension. Avoid mounting in vertical downward orientation.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
