Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30B
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-30B Specifications
- Model: ACPJ12X100-30B
- Type: Double-acting single rod adjustable cylinder
- Bore size: 12mm (0.47")
- Stroke: 100mm (3.94")
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Port size: M5x0.8 (PT1/8 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Foot-mounted (ISO 15552 standard)
- Rod thread: M6x1.0
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Weight: 0.45kg (0.99lb)
- Dimensions: 155mm(L) × 32mm(W) × 32mm(H) (6.10"×1.26"×1.26")
- Piston speed: 50–700mm/s (with cushion)
- Protection rating: IP54 (standard dust/moisture resistance)
A space-saving pneumatic actuator with precision stroke adjustment, featuring dual adjustable rubber cushions for smooth end-of-stroke deceleration. The anodized aluminum construction ensures corrosion resistance, while the integrated mounting slots enable flexible installation. Requires 5μm filtered air and ISO VG32 hydraulic oil lubrication for optimal performance.
- Precision positioning in SMT pick-and-place machines
- Clamping mechanisms in semiconductor test handlers
- Material gate control in automated packaging lines
- Valve actuation in cleanroom equipment
- Door interlock systems for safety cabinets
Installation note:
Adjust cushion screws clockwise to increase damping force (1/4 turn increments max).
Lubricate through air port before initial use. Avoid side load exceeding 5N during operation.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-30B |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
