Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-40
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ12X100-40 Adjustable Compact Cylinder Specifications
- Model Code: ACPJ12X100-40
- Type: Double-acting adjustable cushion cylinder
- Bore size: Ø12mm
- Stroke: 100mm (customizable 1-300mm)
- Operating pressure: 0.15–0.8 MPa
- Piston speed: 50-700mm/s
- Cushion type: External adjustable rubber bumper
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Mounting type: Basic (no flange) with 40mm accessory spacing
- Material: Aluminum alloy barrel, chrome-plated steel rod
- Seal material: Nitrile butadiene rubber (NBR)
- Temperature range: -20℃ to 80℃
- Weight: 280g ±5% (without accessories)
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H) (extended length)
- Rod thread: M6x1.0 external thread
- Protection class: IP54 (standard sealing)
Ultra-slim pneumatic actuator with precision stroke control, featuring dual-position cushion adjustment screws for impact reduction. The anodized surface treatment provides corrosion resistance in humid environments. Requires 5μm filtered compressed air and ISO VG32 turbine oil lubrication (optional oil-free operation).
- PCB board clamping mechanisms in electronics assembly
- Precision paper feed systems in printing machinery
- Micro-positioning in semiconductor handling robots
- Compact door actuators in medical sterilization chambers
- Tool changers in desktop CNC machines
Installation guidelines:
Maximum side load 3N·m. For vertical mounting, use anti-drop mechanism.
Allow 0.5-1mm axial play during mounting. Cushion adjustment requires
1/8 turn increments with hex key (included). Break-in period: 50 cycles
at 50% rated pressure recommended.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-40 |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
