Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-50S
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ12X100-50S Adjustable Compact Cylinder Specifications
- Model: ACPJ12X100-50S
- Type: Double-acting adjustable compact cylinder
- Bore size: 12mm
- Stroke: 100mm (adjustable stroke cushion)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Weight: 0.28kg (excluding accessories)
- Dimensions:
- Extended length: 172mm
- Retracted length: 72mm
- Body width: 24mm
- Mounting height: 50mm
- ISO standard: 6432 (compact cylinder series)
- Protection rating: IP54 (standard seals)
Ultra-slim profile cylinder featuring precision-machined guide bushings and dual adjustable cushioning system. The magnetic piston version (optional) enables position sensing compatibility. Optimized for high-frequency operations up to 5 cycles/sec with minimal vibration transmission. Requires 5μm filtered air with lubrication (ISO VG32 recommended).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Medical device actuation systems
- Compact packaging machine pushers
- Semiconductor wafer processing equipment
Installation note:
Maximum side load 2.5N·m. Use angular misalignment ≤±2° with floating joints.
Lubricate through air supply (oil mist 1-2 drops/m³). Stroke adjustment requires
5mm hex key (included with -50S variant).
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
