Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-50SB
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-50SB Specifications
- Model: ACPJ12X100-50SB
- Type: Double-acting adjustable cushioning cylinder
- Bore size: Φ12mm
- Stroke: 100mm (customizable 25-500mm)
- Operating pressure: 0.15–1.0 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Cushioning: Adjustable buffer (both ends)
- Piston speed: 50-1000mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Mounting type: Standard SW/SC style base (SB variant)
- Weight: 0.52kg (with accessories)
- Dimensions: 154mm(L) × 40mm(W) × 40mm(H)
- Rod end thread: M6×1.0
- Protection rating: IP65 (standard)
Ultra-compact cylinder featuring precision-ground rod and dual adjustable pneumatic cushions for impact control. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight performance. Integrated mounting grooves allow direct sensor installation for position feedback. Requires ISO 8573-1 class 3 or cleaner compressed air.
- PCB handling robots in electronics manufacturing
- Precision clamping devices for CNC tooling
- Pharmaceutical blister packaging machines
- Automated test equipment positioning stages
- Medical device actuation systems
Operation tip:
For optimal cushioning performance, adjust buffer screws in 1/4-turn increments during commissioning.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air systems.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-50SB |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
