Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-50
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-50 Technical Details
- Model: ACPJ12X100-50
- Bore size: 12mm
- Stroke: 100mm (adjustable)
- Adjustment range: 0-50mm (via external stopper)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Fixed rubber bumper + adjustable air cushion
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Mounting type: Basic body mount
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Weight: 320g ±5%
- Dimensions: 172mm(L) × 32mm(W) × 32mm(H)
- ISO standard: 6432
- Protection class: IP54 (standard seals)
Ultra-compact cylinder featuring dual-position stroke adjustment through a mechanical stopper system. The anodized body provides corrosion resistance while maintaining lightweight characteristics. Integrated air cushion mechanism minimizes end-impact noise (adjustable via needle valves). Includes magnetic piston for position sensing compatibility.
- Precision part insertion in PCB assembly robots
- Label positioning mechanisms in packaging lines
- Clamping fixtures for CNC machine tooling
- Medical device actuator components
- Semiconductor wafer handling systems
Installation note:
Lubricate through air ports using ISO VG32 hydraulic oil before initial operation.
For stroke adjustment, loosen lock nut and rotate stopper screw - clockwise for shorter stroke.
Maintain 0.3mm minimum clearance between stopper and cylinder end.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-50 |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
