Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-75SB
2. Front/rear end caps feature threaded connections for enhanced strength and maintenance convenience;
3. Barrel undergoes precision machining followed by hard anodizing treatment for superior wear resistance and durability;
4. Specialized bidirectional sealing structure in piston design ensures compact dimensions with integrated oil reservoir functionality;
5. Space-optimized compact configuration minimizes installation footprint;
6. Perimeter magnetic switch grooves enable flexible sensor mounting options;
7. Multiple standardized mounting accessories available for system integration;
Category: Adjustable Cylinders | Brand: AirTAC | Series: ACPJ
AirTAC ACPJ12X100-75SB Adjustable Compact Cylinder Specifications
- Model: ACPJ12X100-75SB
- Type: Adjustable cushion compact pneumatic cylinder
- Bore size: 12mm
- Stroke: 100mm
- Operating pressure: 0.05–0.9 MPa
- Buffer type: Adjustable air cushion (dual-side)
- Mounting style: Foot-mounted (Standard ISO 6432)
- Rod end type: Double male thread (M5×0.8)
- Material: Aluminum alloy barrel/stainless steel rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Port size: M5×0.8 (Rc1/8 adaptor included)
- Piston speed: 50–700 mm/s
- Weight: 0.45kg ±3%
- Dimensions: 130mm(L) × 25mm(W) × 25mm(H) (Fully retracted)
- Protection rating: IP54 (standard dust/moisture resistance)
- Lubrication: Pre-lubricated (Grease-free operation)
A space-saving cylinder with precision-adjustable cushioning, featuring twin adjustable needle valves for controlled deceleration. The anodized aluminum body ensures corrosion resistance, while the chrome-plated piston rod provides enhanced durability. Optimized for high-frequency cyclic operations with minimal stick-slip effect.
- PCB handling robots in electronics manufacturing
- Precision clamping devices in CNC tool changers
- Label applicators in packaging lines
- Valve actuators in medical analyzers
- Paper feed mechanisms in printing equipment
Installation note:
For optimal performance, maintain 0.3–0.5mm alignment tolerance during mounting.
Use locknuts (not included) for vibration-prone applications. Lubricate every 500,000 cycles
using ISO VG32 hydraulic oil if operated beyond 60℃.
| Property | Property Value |
|---|---|
| sku | ACPJ12X100-75SB |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | 100mm |
