Airtac ACQD Double Acting Compact Cylinder ACQD100X10
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X10 Double Rod Compact Cylinder Specifications
- Model: ACQD100X10
- Type: Double-acting thin series cylinder
- Bore size: Ø100 mm
- Stroke: 10 mm (Standard stroke range: 10-300 mm)
- Operating pressure: 0.15-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (MF1), front flange (MF2), rear double flange (MF3)
- Port size: PT1/4 (NPT1/4 optional)
- Piston rod thread: M16x1.5 (Double rod synchronized output)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR rubber (high wear-resistant seal ring)
- Weight: 2.8 kg ±3%
- Dimensions: L180mm x W140mm x H100mm (Total length includes stroke)
- Piston speed: 50-700 mm/s (Lubricated condition)
- Repetition accuracy: ±0.5 mm
Ultra-flat profile cylinder (25% thinner than standard models) with dual synchronized piston rods for balanced bidirectional force transmission. Features precision honed tube and double lip seals for minimal internal leakage. The hexagonal mounting surfaces enable secure installation alignment. Includes magnetic piston version (ACQDQ series) for position sensing compatibility.
- Clamping fixtures in CNC machining centers
- Parallel gripper mechanisms in robotic arms
- Precision alignment systems in semiconductor handling
- Vertical lifting platforms in packaging machinery
- Synchronized tensioning devices in web processing
Installation notes:
Maintain rod parallelism within 0.2mm/m during mounting. Use flexible couplings when connecting to guided mechanisms. Lubricate with ISO VG32 hydraulic oil for initial operation. Avoid side loads exceeding 30N on piston rods.
Critical parameters:
Maximum side load capacity: 147N (at full extension)
Allowable eccentricity: ≤0.5mm
Minimum operating pressure: 0.1 MPa (with reduced output)
| Property | Property Value |
|---|---|
| sku | ACQD100X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
