Airtac ACQD Double Acting Compact Cylinder ACQD100X100S
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X100S Double Rod Thin Cylinder Specifications
- Model: ACQD100X100S
- Type: Double-acting compact cylinder (dual rod)
- Bore size: 100mm
- Stroke: 100mm (±50mm per side)
- Material: Aluminum alloy barrel, chrome-plated steel piston rod
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/4 (NPT1/4 optional)
- Mounting style: Standard MF1 (front flange) with multiple mounting holes
- Rod end type: Female thread M10×1.25 (both ends)
- Seal material: NBR + polyurethane hybrid seals
- Weight: 4.5kg (without accessories)
- Dimensions: 298mm(L) × 118mm(W) × 152mm(H) (at mid-stroke)
- Max theoretical force: 706N @0.63MPa
- Speed range: 50–750mm/s
- Position detection: Compatible with magnetic sensors (sensor slot included)
Ultra-flat profile cylinder (40% thinner than standard models) designed for space-constrained automation systems. Features symmetrical force output with dual rod configuration and anti-rotation mechanism. Corrosion-resistant construction with hard anodized barrel surface. Includes built-in cushioning adjustment screws and wear-resistant guide bushings.
- Precision clamping in CNC tool changers
- Parallel gripper mechanisms in robotic arms
- Vertical lifting platforms in semiconductor handling
- Synchronized positioning in glass panel production lines
- Balanced force applications in automotive welding jigs
Installation tips:
Maintain 0.5mm minimum clearance between rods during alignment.
Use flexible couplings for lateral force absorption.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Critical note:
Not suitable for side load applications exceeding 15N·m torque.
Requires 5μm filtered air supply when used with rod-end accessories.
| Property | Property Value |
|---|---|
| sku | ACQD100X100S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
