Airtac ACQD Double Acting Compact Cylinder ACQD100X100SB
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X100SB Dual Rod Thin Series Cylinder Specifications
- Model: ACQD100X100SB
- Type: Double-acting dual rod cylinder
- Bore diameter: 100mm
- Stroke: 100mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-1000mm/s
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting style: Basic type (MF1) with multiple mounting options
- Port size: G3/8 (standard) or optional NPT1/2
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated steel
- Seal material: NBR (standard) / PU (optional)
- Weight: 6.8kg (dry, without accessories)
- Dimensions (L×W×H):
- Total length: 292mm (100mm stroke)
- Body width: 100mm
- Height with rods: 154mm (including protruding rods)
- Compact profile: 42mm minimum installation clearance
Ultra-slim dual rod pneumatic cylinder engineered for space-constrained applications requiring symmetrical force distribution. Features twin chrome-plated piston rods for enhanced stability and reduced lateral deflection during operation. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight performance (30% lighter than standard cylinders). Includes magnetic piston for sensor compatibility.
- Precision alignment systems in semiconductor manufacturing
- Simultaneous clamping mechanisms in CNC fixtures
- Bidirectional actuation in packaging sealing machines
- Material handling robots requiring symmetrical force output
- Printing press roller adjustment systems
Installation guidelines:
Maintain parallel alignment of dual rods during mounting.
Use locknuts (included) for rod-end load connections.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
Allow 5mm thermal expansion clearance at both ends.
| Property | Property Value |
|---|---|
| sku | ACQD100X100SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
