Airtac ACQD Double Acting Compact Cylinder ACQD100X125B
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X125B Double Rod Compact Cylinder Specifications
- Model: ACQD100X125B
- Bore size: 100mm
- Stroke: 125mm
- Operation: Double-acting
- Working pressure: 0.15-0.8 MPa (21.7-116 psi)
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable buffer (both ends)
- Mounting style: Basic type (Standard) / Optional: MF1 front flange, MY1 series brackets
- Port size: Rc1/4 (NPT1/4 optional)
- Piston rod material: Hard anodized aluminum alloy
- Seal material: NBR (Nitrile rubber) standard / Optional polyurethane seals
- Weight: 5.2kg (11.46 lbs)
- Dimensions: 230mm(L) × 100mm(Bore W) × 126mm(H) (Cylinder body only)
- Total extended length: 230mm + 2×125mm = 480mm
- Rod diameter: 25mm (both ends)
- Rod thread: M12×1.75 (both ends)
- Protection rating: IP54 (standard)
Ultra-slim profile cylinder with dual rod configuration delivers balanced force output in both directions. Features chrome-plated piston rods with wear-resistant scrapers, and adjustable cushioning to minimize impact at stroke ends. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight performance. Requires 40μm filtered lubricated air (ISO8573-1 class 4).
- Precision clamping systems in CNC tool changers
- Simultaneous lifting mechanisms in material handling
- Bidirectional positioning in semiconductor manufacturing
- Synchronized gate control in packaging lines
- Automated door locking systems with dual-side engagement
Installation note:
Maintain parallel alignment of dual rods during mounting. Use flexible couplings when connecting to driven components. Lubricate through air supply (ISO VG32 equivalent oil mist) with 1 drop/minute oil feed rate. Avoid side load exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | ACQD100X125B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
