Airtac ACQD Double Acting Compact Cylinder ACQD100X125SB
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X125SB Double Rod Thin Cylinder Specifications
- Model: ACQD100X125SB
- Type: Double rod compact cylinder (ISO 21287 compliant)
- Bore size: 100mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Rod thread: M16×1.5 (dual rod ends)
- Mounting type: Basic (standard) / MF1 front flange / MB1 foot
- Material: Aluminum alloy barrel, hardened chrome-plated piston rod
- Seal material: NBR (standard) / optional FKM
- Protection rating: IP65 (rod extended state)
- Weight: 2.8kg (excluding accessories)
- Dimensions: 185mm(L) × 100mm(W) × 63mm(H) (retracted length)
Ultra-slim profile cylinder (63mm height) with symmetrical dual rod design for balanced force transmission. Features anti-rotation mechanism and precision honed tube for smooth operation. Ideal for space-constrained applications requiring synchronized bi-directional movement. Requires 5μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- PCB handling robots in electronics manufacturing
- Clamping fixtures for CNC machining centers
- Glass panel transfer systems
- Pharmaceutical blister packaging machines
- Automated conveyor diverters
Installation tip:
Maintain 0.5mm minimum lateral clearance between rods and adjacent components.
For vertical mounting, use MB1 foot style with 4×M8 fasteners (not included).
Relubricate every 3 months under continuous operation.
| Property | Property Value |
|---|---|
| sku | ACQD100X125SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
