Airtac ACQD Double Acting Compact Cylinder ACQD100X150SB
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X150SB Double Rod Slim Cylinder Specifications
- Model: ACQD100X150SB
- Type: Double-acting, dual rod compact cylinder
- Bore size: 100mm
- Stroke: 150mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M14×1.5 (G1/2 optional)
- Mounting type: Foot-mounted (MF1 standard)
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel
- Seals: NBR (standard)/PU (optional)
- Weight: 3.8kg ±2%
- Dimensions:
- Total length: 318mm (stroke + cylinder body)
- Body width: 100mm (excluding mounting lugs)
- Height: 52mm (including rod ends)
- Rod diameter: 25mm (per rod)
- ISO standard: 6431 (modified)
- Protection rating: IP54 (standard)/IP67 (optional)
Ultra-slim profile cylinder with symmetrical dual rod design enables balanced force distribution and precise linear motion control. Features corrosion-resistant construction with 0.5μm Ra rod surface finish for minimal seal wear. The 20% reduced cross-section height vs standard cylinders allows installation in confined spaces.
| Property | Property Value |
|---|---|
| sku | ACQD100X150SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
