Airtac ACQD Double Acting Compact Cylinder ACQD100X200S
2. Features C-shaped retaining rings for cylinder body and end cap fixation, with a riveted piston-rod structure for compactness and reliability;
3. Precision honed cylinder bore ensures superior wear resistance and extended durability;
4. Extended guide distance on front end cap enhances guiding performance;
5. Ultra-slim profile design optimizes space utilization in confined installations;
6. Integrated sensor grooves around the cylinder body simplify sensor mounting;
7. Multiple mounting accessories available for versatile configurations;
Category: Double Rod Cylinders | Brand: Airtac | Series: ACQD
AirTAC ACQD100X200S Double Rod Thin Cylinder Specifications
- Model: ACQD100X200S
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore diameter: 100mm
- Stroke: 200mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic foot mounting (MF1) with optional flange/clevis
- Port size: G3/8 (M14×1.5 thread)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Rod material: Hard chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Weight: 2.5kg (without accessories)
- Dimensions: 436mm(L) × 100mm(W) × 114mm(H)
- Protection rating: IP54 (standard), IP67 with optional wiper
- Lubrication: Pre-lubricated (Oil-free operation possible)
Ultra-slim profile cylinder (38% thinner than standard models) with dual rod configuration for symmetrical force transmission. Features a reinforced end lock structure and wear-resistant guide bands, achieving over 3,000km service life at rated load. Includes magnetic piston for sensor integration (sensor not included).
- Precision positioning in semiconductor handling systems
- Synchronized clamping mechanisms in auto parts assembly
- Vertical lifting platforms in packaging lines
- Gate control in injection molding machines
- Material transfer in cleanroom environments
Installation note:
Maintain ≤0.15mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use auxiliary support brackets (sold separately). Lubricate rod surfaces monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | ACQD100X200S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
