Airtac ACQD125 Double-rod Compact Cylinder ACQD125X100SB
2. Features C-shaped retaining rings for cylinder body and end cover fixation, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Special-shaped bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir functionality;
5. Space-saving design effectively minimizes installation footprint;
6. Pre-machined sensor grooves along cylinder periphery facilitate easy sensor mounting.
Category: Double Rod Cylinders, Brand: AIRTAC, Series: ACQD125
AirTAC ACQD125X100SB Double Rod Compact Cylinder Specifications
- Model: ACQD125X100SB
- Type: Double rod, thin series pneumatic cylinder
- Bore size: 125mm
- Stroke: 100mm (standard) - customizable up to 500mm
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Fixed buffer + adjustable cushioning
- Mounting type: Basic (axial foot mounting) - optional flange/bracket kits available
- Port size: PT1/2 (G1/2 optional)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU (optional FKM for high temp)
- Protection rating: IP54 (standard) / IP67 with optional wiper
- Weight: 2.8kg (bare cylinder) / 3.1kg with accessories
- Dimensions: 205mm(L) × 125mm(W) × 53mm(H)
Ultra-flat profile cylinder with symmetrical dual rod design for balanced force distribution. Features triple sealing system (rod seals, piston seals, and wipers) for leak-proof operation. Precision honed tube ensures smooth movement with ≤0.5mm lateral play. Integrated magnet slots for sensor compatibility (inductive or reed switches).
- High-density automation cells in electronics assembly
- Clamping fixtures for CNC machining centers
- Vertical lift mechanisms in packaging machinery
- Precision positioning in semiconductor wafer handling
- Medical device actuation systems
Installation tip:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
every 50km of stroke travel. Avoid side loads exceeding 30N. For vertical installations,
use counterbalance valves when handling payloads >15kg.
| Property | Property Value |
|---|---|
| sku | ACQD125X100SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 100mm |
