Airtac ACQD140 Double Rod Compact Cylinder ACQD140X125S
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X125S Double Rod Thin Cylinder Specifications
- Model: ACQD140X125S
- Type: Double-acting, dual rod compact cylinder
- Bore size: 140mm
- Stroke: 125mm (customizable 25-300mm)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable elastic buffer
- Mounting style: Basic type (MF1) with front flange
- Port size: M16×1.5 (G1/2 optional)
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Aluminum alloy hard anodized
- Piston rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR + PU combination
- Weight: 5.8kg ±2%
- Dimensions (L×W×H):
- Total length: 323mm (stroke 125mm)
- Body width: 160mm
- Height with rods: 192mm
- Mounting hole spacing: 130mm×130mm
- Rod thread: M16×1.5
Ultra-flat dual rod cylinder designed for precision force balancing applications. Features symmetrical load distribution with twin piston rods and wear-resistant composite seals. The hard-anodized barrel provides exceptional corrosion resistance in humid environments. Integrated buffer adjustment allows fine-tuning of end-position damping without disassembly.
- Precision press mechanisms in PCB manufacturing
- Synchronized clamping systems for injection molding
- Material handling grippers with balanced force output
- Automated textile machinery tension control
- Semiconductor wafer transfer systems
Installation note:
Requires minimum 0.3mm/m alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side loads exceeding 30N on piston rods.
| Property | Property Value |
|---|---|
| sku | ACQD140X125S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 125mm |
