Airtac ACQD140 Double Rod Compact Cylinder ACQD140X150S
$386.14
Regular price
$393.64
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQD140X150S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQD140 Series Double Rod Cylinder (AirTAC)
1. JIS Standard compliant design ensures international compatibility;
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil through air supply (1/1000 ratio).
Avoid lateral load exceeding 15N. For vertical mounting,
use guided rail kits (model RG10-200 optional).
Critical note:
Maximum side load capacity varies with stroke length -
reduce operating pressure by 20% when stroke exceeds 200mm.
Always install with 0.5mm minimum clearance from adjacent components.
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X150S Double Rod Thin Cylinder Specifications
- Model: ACQD140X150S
- Type: Double rod compact cylinder (with magnetic piston)
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1) with through hole design
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M10x1.25 (both ends)
- Material: Aluminum alloy barrel / Hard anodized piston rod
- Seal material: NBR (nitrile rubber) with wear-resistant ring
- Weight: 1.3kg (with standard accessories)
- Dimensions: 210mm(L) × 63mm(W) × 63mm(H)
- Max theoretical force: 502N @0.7MPa (push/pull)
- Speed range: 50–800mm/s (with cushion adjustment)
Ultra-slim profile cylinder (only 63mm cross-section) designed for space-constrained automation systems. Features symmetrical dual rod configuration for balanced force output and position detection via magnetic sensors. The through-hole mounting design allows flexible installation in multi-axis applications.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Vertical lift systems in pharmaceutical packaging lines
- Synchronized material transfer in automotive assembly
- Paper feeding mechanisms in digital printing equipment
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil through air supply (1/1000 ratio).
Avoid lateral load exceeding 15N. For vertical mounting,
use guided rail kits (model RG10-200 optional).
Critical note:
Maximum side load capacity varies with stroke length -
reduce operating pressure by 20% when stroke exceeds 200mm.
Always install with 0.5mm minimum clearance from adjacent components.
| Property | Property Value |
|---|---|
| sku | ACQD140X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 150mm |
