Airtac ACQD140 Double Rod Compact Cylinder ACQD140X175S
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X175S Double Rod Thin Cylinder Specifications
- Model: ACQD140X175S
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: Ø140 mm
- Stroke: 175 mm
- Operating pressure: 0.1–0.9 MPa
- Action type: Double-acting
- Cushioning: Adjustable rubber cushion (PU material)
- Mounting styles: MF1/MF2 front flange, MB1/MB2 rear flange, MP4 foot mounting
- Port size: 1/4" NPT or G1/4 (optional)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (standard)/FKM (optional)
- Temperature range: -20℃ to 80℃
- Protection rating: IP65 (rod gland side)
- Weight: 2.8 kg (without accessories)
- Dimensions: 340mm(L) × 140mm(W) × 150mm(H) (including mounting brackets)
Ultra-slim profile cylinder (30% thinner than standard models) with symmetrical dual rod design enables balanced force output and precise linear motion control. Features corrosion-resistant construction with anodized barrel and integrated magnet for position sensing compatibility. Optional auto switch models available (e.g., CS1 series).
- High-density automation equipment requiring space optimization
- Precision clamping mechanisms in CNC tooling systems
- Bidirectional actuation in packaging/labeling machinery
- Material handling systems requiring balanced force distribution
- Cleanroom-compatible production lines (FKM seal version)
Installation note:
Maintain 0.5-1mm clearance between rod ends and load during alignment.
Lubricate with ISO VG32 hydraulic oil (non-detergent). Avoid side loads exceeding
30% of maximum thrust. Recommend 5,000km maintenance interval or 6-month
lubrication refresh (whichever comes first).
| Property | Property Value |
|---|---|
| sku | ACQD140X175S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 175mm |
