Airtac ACQD140 Double Rod Compact Cylinder ACQD140X175SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X175SB Double Rod Compact Cylinder Specifications
- Model: ACQD140X175SB
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: Ø140 mm
- Stroke: 175 mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (with cushion)
- Port size: PT1/2 (G1/2 optional)
- Cushion type: Adjustable buffer at both ends
- Mounting style: Basic (axial mounting accessories available)
- Ambient temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated steel (Cr equivalent: 0.8-1.2μm)
- Seal material: NBR (nitrile rubber)
- Weight: 8.7 kg (with standard accessories)
- Dimensions:
- Length: 433 mm (retracted)
- Width: 162 mm (max body width)
- Height: 162 mm (including mounting bosses)
- Protection rating: IP54 (standard), IP67 (optional w/rod scraper)
Ultra-flat profile cylinder (40% slimmer than standard models) featuring synchronized dual rod movement for balanced force distribution. Precision-ground piston rods with 4-stage chroming process ensure ≤0.05mm runout tolerance. Integrated magnetic sensor slots (M9x1) on both ends for position feedback compatibility. Pre-lubricated for maintenance-free operation (relubrication interval: 2,000km travel distance).
- High-precision press machines requiring symmetrical force
- Automated palletizing systems with space constraints
- Semiconductor wafer handling equipment
- Parallel gripper mechanisms in robotics
- Vertical lifting platforms needing dual-point support
Installation note:
Requires 0.5-1mm lateral clearance for thermal expansion. For vertical mounting,
use locking nuts (M12x1.25) on both rods. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Air filtration: 5μm minimum.
| Property | Property Value |
|---|---|
| sku | ACQD140X175SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 175mm |
