Airtac ACQD140 Double Rod Compact Cylinder ACQD140X200SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X200SB Double Rod Compact Cylinder Specifications
- Model: ACQD140X200SB
- Type: Double rod thin-series pneumatic cylinder
- Bore size: Ø140 mm
- Stroke: 200 mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Fixed rubber buffer (both ends)
- Mounting style: Basic type (optional foot/mounting flange)
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/2 (G1/2 optional)
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel (S45C)
- Seal type: NBR + PTFE combination
- Weight: 8.6 kg (dry, without accessories)
- Dimensions: 456mm(L) × 140mm(W) × 150mm(H)
- ISO standard: 15552 compliant design
Ultra-slim profile cylinder (40% thinner than standard models) with symmetrical dual rod configuration enables balanced bidirectional force transmission. Features corrosion-resistant construction and integrated cushioning mechanism for smooth end-of-stroke deceleration. Designed for high-precision positioning in space-constrained applications.
- High-speed pick-and-place systems in electronics assembly
- Simultaneous clamping mechanisms in CNC fixtures
- Material handling gate controls
- Synchronized lifting platforms
- Automated packaging line actuators
Installation note:
Maintain parallel alignment of dual rods during operation. Lubricate with ISO VG32 hydraulic oil
or equivalent. Maximum side load capacity: 450N. Allow 15mm clearance for rod extension.
| Property | Property Value |
|---|---|
| sku | ACQD140X200SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <200mm> |
