Airtac ACQD140 Double Rod Compact Cylinder ACQD140X20SB
$281.45
Regular price
$288.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQD140X20SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQD140 Series Double Rod Cylinder (AirTAC)
1. JIS Standard compliant design ensures international compatibility;
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
Installation note:
Maintain 0.05mm/m alignment tolerance during mounting. Use M6×1.0 mounting screws
with 12Nm torque limit. For horizontal installations, add intermediate support when
stroke exceeds 150mm. Lubricate with ISO VG32 hydraulic oil before initial operation.
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X20SB Double Rod Thin-Type Cylinder Specifications
- Model: ACQD140X20SB
- Type: Double-acting, dual rod compact cylinder
- Bore size: 140mm
- Stroke: 20mm (customizable 10-300mm)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Cushioning: Adjustable rubber buffer
- Mounting style: Basic type (MF1) with standard mounting holes
- Material: Aluminum alloy barrel, hard anodized piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 1.8kg ±2% (without accessories)
- Dimensions: 180mm(L) × 140mm(W) × 50mm(H) (at mid-stroke position)
- Piston rod diameter: 25mm (chrome-plated)
- Max theoretical thrust: 1387N @0.63MPa
- ISO standard: 6431/VDMA 24562
Ultra-flat profile cylinder optimized for space-constrained automation systems. Features dual guided piston rods for enhanced stability and anti-rotation performance. Precision honed inner tube ensures ≤0.5μm surface roughness, achieving 98% mechanical efficiency. Includes built-in magnet for position sensing compatibility.
Typical Applications:
- High-speed sorting arms in logistics robots
- Precision clamping mechanisms for CNC tool changers
- Vertical lift systems in semiconductor wafer handling
- Synchronized pressurization in battery module assembly
- Parallel actuation in automotive welding jigs
Installation note:
Maintain 0.05mm/m alignment tolerance during mounting. Use M6×1.0 mounting screws
with 12Nm torque limit. For horizontal installations, add intermediate support when
stroke exceeds 150mm. Lubricate with ISO VG32 hydraulic oil before initial operation.
Critical parameters:
- Max side load capacity: 245N at cylinder center
- Max piston speed: 500mm/s (cushioned)
- Repeat positioning accuracy: ±0.1mm
- Air filtration requirement: 5μm absolute
| Property | Property Value |
|---|---|
| sku | ACQD140X20SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <20mm> |
