Airtac ACQD140 Double Rod Compact Cylinder ACQD140X300SB
$500.40
Regular price
$507.90
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQD140X300SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQD140 Series Double Rod Cylinder (AirTAC)
1. JIS Standard compliant design ensures international compatibility;
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
Installation note:
Maintain 0.1-0.3mm alignment tolerance during mounting. For vertical installations,
use rod-end support brackets (accessory code: BR-140S). Lubricate rods monthly with
ISO VG32 hydraulic oil if operated in dusty environments.
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X300SB Double Rod Compact Cylinder Specifications
- Model: ACQD140X300SB
- Type: Double rod, thin series ISO cylinder
- Bore size: 140mm
- Stroke: 300mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Operating medium: Clean air (ISO8573-1:2010 Class 3)
- Port size: M27×2 (G1" optional)
- Mounting style: Basic (MF1) with multiple mounting options
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal type: NBR + PTFE wear band
- Temperature range: -20℃ to 80℃
- Weight: 12.8kg ±2%
- Dimensions:
- Extended length: 648mm
- Retracted length: 348mm
- Body width: 160mm
- Height with rods: 196mm
- Lubrication: Pre-lubricated (non-re-lube design)
- Protection rating: IP65 (rod seals)
Ultra-flat profile cylinder optimized for high moment load resistance, featuring dual piston rods for balanced force distribution. The T-slot mounting groove allows flexible installation in confined spaces. Special buffer design reduces end-impact noise to ≤70dB(A).
Typical Applications:
- Automated palletizing systems requiring symmetrical force
- Press-fit mechanisms in automotive assembly lines
- Precision glass panel handling equipment
- High-cycle packaging machines (up to 1,200 cph)
- Metal stamping die cushion systems
Installation note:
Maintain 0.1-0.3mm alignment tolerance during mounting. For vertical installations,
use rod-end support brackets (accessory code: BR-140S). Lubricate rods monthly with
ISO VG32 hydraulic oil if operated in dusty environments.
| Property | Property Value |
|---|---|
| sku | ACQD140X300SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | 300mm |
