Airtac ACQD140 Double Rod Compact Cylinder ACQD140X40SB
2. C-shaped retaining ring secures cylinder body to front/rear covers for compact and reliable construction;
3. Precision-machined bore with hard anodized treatment enhances wear resistance and operational longevity;
4. Asymmetric bidirectional piston seal configuration combines space efficiency with integrated oil reservoir functionality;
5. Ultra-slim profile optimizes installation space utilization in confined environments;
6. Perimeter sensor slots enable flexible and tool-free proximity sensor mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD140
AirTAC ACQD140X40SB Double Rod Thin Cylinder Specifications
- Model: ACQD140X40SB
- Type: Double-acting, dual rod compact cylinder
- Bore size: Ø140 mm
- Stroke: 40 mm (customizable 10-300 mm)
- Operating pressure: 0.05-0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: 1/2" NPT (G1/2 optional)
- Piston rod thread: M16×1.5 (dual rod)
- Mounting type: Basic (axial foot optional)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Protection rating: IP54 (standard) / IP67 (optional)
- Weight: 2.8 kg ±5%
- Dimensions: 180mm(L) × 140mm(W) × 60mm(H)
- Piston speed: 50-750 mm/s
- Durability: ≥3,000 km (ISO 15552 standard)
Ultra-flat cylinder (height only 60mm) designed for space-constrained automation systems. Features symmetrical dual rod structure for balanced force distribution and precise linear motion. The anodized aluminum body with chromium-plated piston rods resists corrosion in humid environments.
- PCB press-fit mechanisms in electronics assembly
- Clamping fixtures for CNC machining centers
- Vertical lifting platforms in logistics sorting systems
- Precision alignment systems for optical component production
- Packaging machine gate control with space limitations
Installation note:
Maintain parallel alignment during mounting (max 0.2mm/m deviation).
Use flexible couplings when connecting to rigid mechanisms.
Lubricate rod ends with ISO VG32 hydraulic oil monthly in continuous operation.
| Property | Property Value |
|---|---|
| sku | ACQD140X40SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <140mm> |
| Stroke | <40mm> |
