Airtac ACQD160 Double Acting Slim Cylinder ACQD160X10SB
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X10SB Double Rod Thin Cylinder Specifications
- Model: ACQD160X10SB
- Type: Double-acting compact cylinder (dual rod)
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 10mm (customizable up to 300mm)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic type (optional flange/clevis kits)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR wear-resistant seals
- Weight: 0.55kg (without accessories)
- Dimensions:
- Extended length: 180mm
- Retracted length: 170mm
- Body width: 25mm
- Mounting height: 32mm
Ultra-slim profile cylinder (16mm height reduction vs standard models) with symmetrical dual-rod design for balanced force distribution. Features anti-rotation mechanism and integrated magnet for sensor mounting. Certified to ISO 6432 and JIS B 8379 standards with 2,000km lifespan under rated conditions. Requires ISO 8573-1 class 3 or cleaner air.
- High-density automation cells (electronics PCB handling)
- Medical device positioning systems
- Packaging machine gripper mechanisms
- Precision alignment in semiconductor wafer stages
- 3D printer Z-axis compensation systems
Installation tip:
Maintain 0.5-1mm lateral clearance during mounting to prevent binding.
Lubricate with ISO VG32 turbine oil before initial use. Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | ACQD160X10SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | <10mm> |
