Airtac ACQD160 Double Acting Slim Cylinder ACQD160X150S
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X150S Double Rod Thin Cylinder Specifications
- Model: ACQD160X150S
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: 160mm
- Stroke: 150mm (customizable up to 500mm)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange/Foot mount (MF1), optional rear flange
- Port size: PT1/4 (G1/4 optional)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seals: NBR standard (FKM available for high temp)
- Ambient temperature: -20℃ to 80℃
- Weight: 6.8kg (with standard fittings)
- Dimensions: 310mm(L) × 168mm(W) × 168mm(H)
- Rod thread: M20×1.5 (both ends)
- Protection rating: IP65 (wipers included)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil)
Ultra-flat profile cylinder with symmetrical dual rod design for balanced force distribution. Features through-rod construction enabling simultaneous actuation on both sides, ideal for precision alignment tasks. Anodized surface treatment provides corrosion resistance in humid environments. Optional magnetic piston version (ACQD160X150S/M) available for position sensing.
- Clamping fixtures in CNC machining centers
- Vertical lift mechanisms for assembly robots
- Simultaneous door locking in industrial ovens
- Paper feed synchronization in printing machinery
- Position balancing in solar panel tracking systems
Installation tip:
Maintain 0.5mm minimum clearance between rods and load attachments
to prevent side load. Use alignment couplers when connecting to
guided mechanisms. Lubricate rod surfaces monthly in high-cycle
applications (>500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQD160X150S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | 150mm |
