Airtac ACQD160 Double Acting Slim Cylinder ACQD160X175S
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X175S Double Rod Thin Cylinder Specifications
- Model: ACQD160X175S
- Type: Double-acting compact cylinder (dual rod)
- Bore size: 160mm
- Stroke: 175mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Port size: 2×G1/2 (female thread)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR + PU combination
- Mounting style: Basic (axial foot optional)
- Cushioning: Adjustable air cushion (both ends)
- Protection rating: IP54 (standard wiper)
- Weight: 7.8kg (without accessories)
- Dimensions: 373mm(L) × 190mm(W) × 190mm(H)
Ultra-flat profile cylinder (38% slimmer than standard models) with dual synchronized rods for balanced force transmission. Features corrosion-resistant construction and precision-guided piston movement, ideal for applications requiring parallel motion control. Includes magnetic piston for sensor attachment (D-C73 series compatible).
- Automated palletizing systems requiring symmetrical force
- Precision glass panel handling in LCD manufacturing
- Simultaneous clamping in CNC fixture setups
- Bidirectional pressing in battery assembly lines
- Vertical lift mechanisms for cleanroom robotics
Installation guidance:
Maintain 0.5mm minimum alignment tolerance during mounting.
Lubricate with ISO VG32 turbine oil before initial operation.
Recommended air dryness: Pressure dew point 15℃ below ambient.
| Property | Property Value |
|---|---|
| sku | ACQD160X175S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | 175mm |
