Airtac ACQD160 Double Acting Slim Cylinder ACQD160X250S
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X250S Double Rod Thin Cylinder Specifications
- Model: ACQD160X250S
- Type: Double-acting, dual rod compact cylinder
- Bore size: 160mm
- Stroke: 250mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: Basic/Flange (MF1/MF2 optional)
- Port size: G3/8 (NPT1/2 optional)
- Piston rod thread: M20×1.5
- Seal material: NBR/PU (standard), FKM (optional)
- Protection rating: IP65 (dust/water jet resistant)
- Weight: 7.5kg ±2% (excluding accessories)
- Dimensions: 550mm(L) × 180mm(W) × 180mm(H)
- Rod end type: External thread + locknut
- Lubrication: Pre-lubricated (DOP anti-wear oil)
Ultra-flat profile cylinder (40% slimmer than standard models) designed for space-constrained industrial automation. Features dual synchronized piston rods for balanced bidirectional force output (max thrust 19,700N at 0.7MPa). Anti-rotation design ensures precise linear motion alignment. Corrosion-resistant aluminum alloy body with hard chrome-plated rods (3-5μm thickness).
- High-precision press machines requiring symmetric force distribution
- Automated material handling systems with tight vertical clearance
- Electronics assembly clamping fixtures
- Automotive welding jig positioning
- Solar panel lamination equipment
Installation note:
Maintain alignment tolerance ≤0.2mm/m during mounting. Use flexible couplings when lateral forces exceed 10% of axial load. Lubricate rods monthly with ISO VG32 hydraulic oil in high-cycle applications (＞500,000 cycles/year).
| Property | Property Value |
|---|---|
| sku | ACQD160X250S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | <250MM> → <250mm> |
