Airtac ACQD160 Double Acting Slim Cylinder ACQD160X250SB
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X250SB Double Rod Thin Cylinder Specifications
- Full model code: ACQD160X250SB
- Bore size: 160mm
- Stroke: 250mm
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: 2×G3/8 (dual ports each side)
- Cushion type: Fixed cushion + adjustable cushion
- Piston rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Mounting type: Basic (no foot) with axial mounting holes
- Weight: 9.8kg ±2%
- Dimensions:
- Length: 474mm (full extension)
- Width: 190mm (max cylinder body width)
- Height: 160mm (bore diameter)
- ISO standard: 15552 compliant
- Protection rating: IP54 (standard seals)
Ultra-flat dual rod cylinder with symmetrical force output, featuring 50% reduced installation space compared to standard cylinders. Precision honed tube ensures ≤0.05mm inner diameter tolerance. Dual rod design eliminates rotation during operation, ideal for precision alignment applications. Includes anti-collision design with 3mm safety margin at stroke ends.
- High-speed sorting gates in logistics systems
- Simultaneous clamping mechanisms in CNC fixtures
- Parallel lifting platforms in automotive assembly
- Bidirectional tensioning devices in textile machinery
- Precision alignment stages in LCD panel handling
Installation guidelines:
Requires horizontal mounting for optimal performance. Apply ISO VG32 hydraulic oil lubrication.
Allow 15mm clearance on rod ends for thermal expansion. Max side load ≤5% of thrust capacity.
| Property | Property Value |
|---|---|
| sku | ACQD160X250SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | <250MM> → <250mm> |
