Airtac ACQD160 Double Acting Slim Cylinder ACQD160X300S
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X300S Double Rod Thin Cylinder Specifications
- Model: ACQD160X300S
- Series: ACQD Compact Double Rod Series
- Bore size: 160mm
- Stroke: 300mm
- Mounting type: Standard foot mounting (MF1) / Front flange (MF2) optional
- Operating pressure: 0.15–0.8 MPa
- Piston rod material: Hard chrome-plated carbon steel
- Rod diameter: 40mm (both ends)
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/2 (ISO standard)
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: ~6.8kg (without accessories)
- Dimensions: 520mm(L) × 160mm(W) × 230mm(H) (foot mounted)
- Protection rating: IP54 (standard wiper)
- Lubrication: Pre-lubricated (oil-free operation possible)
A space-saving dual-action cylinder with symmetrical force output, featuring 40% reduced installation height compared to standard cylinders. The double rod design ensures precise linear motion control with minimal deflection. Ideal for applications requiring balanced thrust forces and compact footprint. Includes wear-resistant guide bushings for extended service life.
- Clamping fixtures in automated welding systems
- Vertical lifting platforms in material handling
- Precision alignment mechanisms in printing machinery
- Glass cutting equipment positioners
- Battery assembly line press mechanisms
Installation note:
Maintain parallel alignment of both rod ends during mounting.
For vertical installations exceeding 45° angle, use rod-end supports
to prevent side load. Adjust cushion screws gradually (1/4 turn increments)
for optimal deceleration.
| Property | Property Value |
|---|---|
| sku | ACQD160X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | 300mm |
