Airtac ACQD160 Double Acting Slim Cylinder ACQD160X300SB
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X300SB Double Rod Thin Series Cylinder Specifications
- Model: ACQD160X300SB
- Bore size: 160mm
- Stroke: 300mm
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: G3/8
- Mounting type: Basic (no flange)
- Piston rod thread: M16×1.5 (both ends)
- Operating temperature: -20℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65 (standard wiper design)
- Lubrication: Pre-lubricated (oil-free operation possible)
- Repeat accuracy: ±0.5mm
- Max speed: 500-800 mm/s (cushioned)
- Weight: 2.8 kg (excluding accessories)
- Dimensions: 400mm(L) × 160mm(W) × 80mm(H)
- Tubing connection: 10mm push-in fittings (standard)
Ultra-slim profile cylinder with dual extended rods enabling synchronized bi-directional force transmission. Features precision ground stainless steel guide rods and anti-rotation mechanism for stable linear motion. Optional magnetic piston version (add "-M" suffix) for position sensing. Suitable for high-cycle applications with space constraints.
- Precision press mechanisms in PCB assembly
- Simultaneous clamping in fixture systems
- Vertical lifting platforms in packaging lines
- Material positioning in solar panel manufacturing
- Automated door synchronization systems
Installation note:
Maintain parallel alignment of dual rods during mounting.
Use flexible couplings to accommodate minor misalignments.
Recommended air filtration: 5μm with auto-drain function.
| Property | Property Value |
|---|---|
| sku | ACQD160X300SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | 300mm |
