Airtac ACQD160 Double Acting Slim Cylinder ACQD160X30SB
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X30SB Double Rod Thin Cylinder Specifications
- Model: ACQD160X30SB
- Type: Double-acting compact cylinder with dual rod
- Bore size: 160mm (6.3")
- Stroke: 30mm ±1.5mm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: SB-type - basic front flange with mounting holes
- Port size: M5x0.8 (G1/8 adaptor included)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR (Nitrile rubber) standard
- Weight: 3.8kg ±5% (excluding accessories)
- Dimensions:
- Length: 225mm (full retraction)
- Width: 170mm (flange edge to edge)
- Height: 58mm (cylinder body thickness)
- Rod thread: M10x1.25 (both ends)
- Max theoretical force: 2010N @ 0.63MPa
- Air consumption: 6.03L/stroke @ 0.5MPa
Ultra-flat profile cylinder (58mm thickness) designed for space-constrained industrial automation. Features dual symmetrical rods for balanced force transmission and anti-rotation stability. Precision honed aluminum alloy tube with wear-resistant guide bushings ensures smooth operation. Compatible with magnetic sensors for position detection (sensor groove included).
- Clamping fixtures in CNC machining centers
- Precision alignment systems for LCD panel handling
- Vertical lifting mechanisms in packaging lines
- Simultaneous actuation in semiconductor wafer processing
- Parallel gripper configurations in robotics
Installation notes:
- Align rods perpendicular to load movement
- Use swivel joints to prevent side load stress
- Allow 0.5mm thermal expansion gap during mounting
- Lubricate with ISO VG32 turbine oil if non-lubricated air used
| Property | Property Value |
|---|---|
| sku | ACQD160X30SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | 30mm |
