Airtac ACQD160 Double Acting Slim Cylinder ACQD160X75SB
2. Features C-shaped retaining ring fixation between cylinder body and end covers, ensuring compact and reliable construction;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and long-term durability;
4. Innovative asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir capability;
5. Space-saving compact profile optimizes installation space utilization;
6. Pre-machined sensor grooves along cylinder periphery enable convenient proximity switch mounting.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACQD160 （Key technical terms maintained: JIS compliance, C-shaped retaining ring, hard anodized treatment, bidirectional sealing structure, oil reservoir capability, sensor grooves. Optimized phrasing for technical documentation style while preserving original HTML structure.）
AirTAC ACQD160X75SB Double Rod Thin Cylinder Specifications
- Model: ACQD160X75SB
- Type: Double-acting compact cylinder with dual rod
- Bore size: 160mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃ (non-freezing)
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (optional foot/middle trunnion)
- Port size: G1/2 (ISO228/1 standard)
- Piston speed: 50–800 mm/s (lubricated)
- Rod material: Hard chrome-plated steel (4Cr13)
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR + special wear ring
- Weight: 5.2kg ±3% (excluding accessories)
- Dimensions: 275mm(L) × 160mm(W) × 160mm(H) (stroke extended)
- ISO standard: 15552 compliant (VDMA 24562)
- Repeat accuracy: ±0.5mm (under 0.5MPa)
Ultra-flat profile cylinder (30% slimmer than standard models) designed for bidirectional force applications in confined spaces. Features symmetrical load distribution through dual rod configuration and corrosion-resistant hard chrome rods. Includes magnetic piston (SB variant) for position sensing compatibility. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Press machine ejection systems
- Automated palletizing arm synchronization
- EV battery module compression fixtures
- Glass panel flipping mechanisms
- Pharmaceutical blister pack sealing
Installation tips:
Align cylinder axis within 0.2mm perpendicularity tolerance.
Use flexible couplings for stroke-end force absorption.
Maintain 0.3-0.5mm clearance between magnetic sensor and rod surface.
| Property | Property Value |
|---|---|
| sku | ACQD160X75SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 160mm |
| Stroke | 75mm |
