Airtac AirTAC MID Series Double Rod Mini Cylinder MID10X20S
2. Front/rear covers with integrated cushion rings to minimize reversing impact;
3. Versatile rear cover configurations for simplified installation flexibility;
4. Crimped structure securely connects stainless steel cylinder barrel with front/rear covers for enhanced joint reliability;
5. Stainless steel piston rod and cylinder barrel provide corrosion resistance in mildly corrosive environments;
6. Multiple specifications and mounting accessories available for diverse application needs.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MID
AirTAC MID Series Double Rod Mini Cylinder MID10X20S Specifications
- Model: MID10X20S
- Type: Double-acting compact cylinder with dual rod
- Bore size: Ø10mm
- Stroke: 20mm (customizable 1-100mm)
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Rod thread: M4x0.7 (both ends)
- Mounting style: Basic (no built-in mounts)
- Material: Aluminum alloy barrel, hardened stainless steel rod
- Seal type: NBR/PU hybrid seals
- Weight: 128g ±2%
- Dimensions:
- Total length: 68mm (at mid-stroke)
- Body width: 20mm
- Height with rods: 34mm
- Mounting hole spacing: 25mm (longitudinal)
Ultra-compact dual-rod actuator optimized for space-constrained automation. Features symmetrical force output with ±0.5mm repeat positioning accuracy. Corrosion-resistant anodized surface with integrated wear rings ensures 3,000km+ service life. Compatible with ISO 6432 mounting accessories.
- PCB handling robots with dual-arm synchronization
- Micro-dosing valves in pharmaceutical equipment
- Optical lens positioning stages
- Semiconductor wafer clamping mechanisms
- 3D printer filament tensioning systems
Installation tip:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 2N.
For vertical mounting, reduce max speed to 500mm/s to prevent piston chatter.
| Property | Property Value |
|---|---|
| sku | MID10X20S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <20mm> |
