Airtac AirTAC MID Series Double Rod Mini Cylinder MID10X40
2. Front/rear covers with integrated cushion rings to minimize reversing impact;
3. Versatile rear cover configurations for simplified installation flexibility;
4. Crimped structure securely connects stainless steel cylinder barrel with front/rear covers for enhanced joint reliability;
5. Stainless steel piston rod and cylinder barrel provide corrosion resistance in mildly corrosive environments;
6. Multiple specifications and mounting accessories available for diverse application needs.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MID
AirTAC MID10X40 Double Rod Mini Cylinder Technical Details
- Model: MID10X40
- Type: Double-acting mini cylinder with dual rod
- Bore size: Ø10mm (±0.1mm tolerance)
- Stroke: 40mm (adjustable stroke available)
- Operating pressure: 0.05-1.0 MPa
- Max thrust: 7.85N at 0.5MPa (both sides)
- Piston speed: 50-700mm/s (cushioned)
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Weight: 190g ±5g (with rods and mounting accessories)
- Dimensions:
- Body length: 80mm
- Total length (extended): 160mm
- Width: 24mm (including mounting tabs)
- Height: 20mm (main body profile)
- Operating temperature: -20℃ to 80℃
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seals: HNBR (Hydrogenated Nitrile) with wear-resistant ring
- Cushioning: Adjustable rubber buffers at both ends
- Mounting options: Basic type (no bracket), front flange, rear clevis
- ISO standard: 6432 compliant
Ultra-compact dual-rod pneumatic cylinder featuring synchronized bi-directional movement and precise linear motion control. The symmetrical rod design eliminates lateral forces on piston seals, ensuring extended service life (up to 3,000km travel distance). Includes built-in auto-switch mounting slots for sensor integration. Requires ISO 8573-1 class 3 lubricated air (recommended ISO VG32 turbine oil).
- Precision alignment in semiconductor wafer handling
- Simultaneous clamping in micro-injection molding machines
- Z-axis positioning in 3D printing/pick-and-place robots
- Valve actuation in compact analytical instruments
- Bi-directional tensioning in textile machinery
Installation tip:
Maintain 0.5mm minimum clearance between rods during parallel installation.
Use locknuts (included) for rod-end load connections. Lubricate through air port
using 1-2 drops of pneumatic oil monthly in dry environments.
| Property | Property Value |
|---|---|
| sku | MID10X40 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <10mm> |
| Stroke | <40mm> |
