Airtac AirTAC MID Series Double Rod Mini Cylinder MID12X10
2. Front/rear covers with integrated cushion rings to minimize reversing impact;
3. Versatile rear cover configurations for simplified installation flexibility;
4. Crimped structure securely connects stainless steel cylinder barrel with front/rear covers for enhanced joint reliability;
5. Stainless steel piston rod and cylinder barrel provide corrosion resistance in mildly corrosive environments;
6. Multiple specifications and mounting accessories available for diverse application needs.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MID
AirTAC MID12X10 Double-Rod Miniature Cylinder Specifications
- Model: MID12X10
- Type: Double-acting, dual-rod compact cylinder
- Bore size: 12mm (0.47")
- Stroke: 10mm (0.39") ±0.5mm tolerance
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Rubber bumper (non-adjustable)
- Port size: M5×0.8 (1/8" NPT optional)
- Mounting style: Side-mount with 2x M3 threaded holes
- Rod material: Stainless steel SUS304
- Cylinder body: Anodized aluminum alloy
- Seal material: NBR (Nitrile) standard
- Weight: 82g (2.89 oz)
- Dimensions:
- Total length: 63mm (2.48")
- Body width: 20mm (0.79")
- Height (with rods): 26mm (1.02")
- Rod thread: M3×0.5 at both ends
- Max speed: 500mm/s (with cushion)
Ultra-compact dual-rod cylinder designed for precision linear motion in confined spaces. Features synchronized dual-piston movement for balanced force distribution and reduced lateral load. Ideal for applications requiring bi-directional force consistency and minimal deflection. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical equipment
- Optical lens positioning systems
- 3D printer nozzle adjustment mechanisms
- Laboratory sample sorting devices
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rods and adjacent components.
Avoid side loads exceeding 2N. For vertical mounting, use auxiliary guides.
| Property | Property Value |
|---|---|
| sku | MID12X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
