Airtac AirTAC MID Series Double Rod Mini Cylinder MID12X100S
2. Front/rear covers with integrated cushion rings to minimize reversing impact;
3. Versatile rear cover configurations for simplified installation flexibility;
4. Crimped structure securely connects stainless steel cylinder barrel with front/rear covers for enhanced joint reliability;
5. Stainless steel piston rod and cylinder barrel provide corrosion resistance in mildly corrosive environments;
6. Multiple specifications and mounting accessories available for diverse application needs.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MID
AirTAC MID12X100S Double-Rod Miniature Cylinder Specifications
- Model: MID12X100S
- Type: Double-rod compact cylinder (ISO 6432 compliant)
- Bore size: 12mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Port size: M5×0.8 (standard) with NPT1/8 optional
- Piston rod thread: M6×1.0 at both ends
- Mounting options: Basic type (no flange) with optional accessories: MFH-12 front flange or MFH-12R rear flange
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- End covers: Die-cast aluminum
- Piston rod: Stainless steel (SUS304)
- Seals: NBR rubber (-20℃ to 80℃)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Weight: 285g ±5g (without accessories)
- Dimensions:
- Total length: 158mm (stroke 100 + 58mm base)
- Body diameter: 24mm (hexagonal shape)
- Rod length: 30mm extension beyond end covers
- Lubrication: Pre-lubricated (DOP mist lubrication compatible)
- Max speed: 500mm/s (with cushioning)
A space-saving dual-action pneumatic cylinder engineered for precision linear motion in confined spaces. Features synchronized dual-rod output for balanced force distribution and optional position detection through magnetic piston (add "-M" suffix for magnet-equipped version). The hexagonal body design enables tool-free rotation prevention during installation.
- PCB board clamping mechanisms in electronics assembly
- Precision lens positioning in optical equipment
- Dual-gripper coordination in pick-and-place robots
- Valve actuation in compact medical analyzers
- Simultaneous door latch operation in automotive fixtures
Installation tip:
Maintain rod alignment within 0.2mm perpendicular tolerance. For vertical mounting,
use rod-end support brackets (ASNU12 model recommended). Lubricate every 500km of
cumulative stroke travel using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MID12X100S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 100mm |
