Airtac AirTAC MID Series Double Rod Mini Cylinder MID12X15
2. Front/rear covers with integrated cushion rings to minimize reversing impact;
3. Versatile rear cover configurations for simplified installation flexibility;
4. Crimped structure securely connects stainless steel cylinder barrel with front/rear covers for enhanced joint reliability;
5. Stainless steel piston rod and cylinder barrel provide corrosion resistance in mildly corrosive environments;
6. Multiple specifications and mounting accessories available for diverse application needs.
Category: Double Rod Cylinders , Brand: AirTAC , Series: MID
AirTAC MID12X15 Double Rod Mini Cylinder Specifications
- Model: MID12X15
- Type: Double-acting dual rod mini cylinder
- Bore size: 12mm
- Stroke: 15mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Elastic rubber buffer (both ends)
- Port size: M5x0.8 (2 ports)
- Rod diameter: 4mm (both rods)
- Mounting types: Basic (no bracket), optional foot/mounting accessories
- Seal material: Nitrile rubber (NBR) standard
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Weight: 0.12kg (excluding accessories)
- Dimensions: 60mm(L) × 20mm(W) × 20mm(H) (extended length)
- Protection rating: IP40 (standard seals)
- Lubrication: Pre-lubricated (use ISO VG32 oil if required)
Ultra-compact dual-rod pneumatic cylinder optimized for symmetrical force transmission in confined spaces. Features synchronized movement through twin piston rods with precise linear motion control. The chrome-plated rods and corrosion-resistant construction ensure durability in humid environments. Requires 5μm filtered air (lubricated or non-lubricated).
- Precision alignment mechanisms in semiconductor handlers
- Clamping fixtures for PCB assembly robots
- Valve actuation in compact fluid control systems
- Positioning stages for optical lens manufacturing
- Medical device sterilization chamber door interlocks
Installation note:
Maintain 0.5-1mm clearance between rods and adjacent components.
For vertical mounting, use speed controller (ASC-06) to prevent piston free-fall.
Lubricate every 3 months under continuous operation.
| Property | Property Value |
|---|---|
| sku | MID12X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
