Airtac B01-SDAJ Special Cylinder B01-SDAJ40X60-30B
AirTAC B01-SDAJ40X60-30B Special Purpose Cylinder Specifications
- Model: B01-SDAJ40X60-30B
- Bore size: 40mm
- Stroke: 60mm
- Mounting type: Standard foot & front flange (B-type)
- Operation type: Double-acting
- Working pressure range: 0.05-1.0 MPa
- Max. theoretical thrust: 1256N @0.63MPa
- Piston speed: 50-1000mm/s
- Cushioning type: Adjustable cushioning (both ends)
- Ambient temperature: -20℃ to 80℃
- Port size: G1/8 (M5x0.8 optional)
- Body material: Aluminum alloy (hard anodized)
- Seal material: NBR/PU (standard), optional FKM
- Rod material: Chrome-plated steel
- Protection rating: IP65 (dust tight & water jet resistant)
- Weight: 1.8kg ±3%
- Dimensions:
- Extended length: 218mm
- Retracted length: 158mm
- Body width: 56mm
- Mounting hole spacing: 30mm (vertical) × 40mm (horizontal)
High-precision industrial cylinder with enhanced lateral load capacity, featuring triple sealing structure for leak-proof operation. The hard-anodized barrel surface provides exceptional wear resistance in high-cycle applications (up to 3,000km service life). Includes magnetic piston for position sensing compatibility.
- Vertical press machine tool clamping
- Automated conveyor gate actuators
- Plastic injection molding ejectors
- Textile machinery tension control
- Semiconductor wafer handling systems
Installation note:
Ensure proper alignment of mounting surfaces (flatness ≤0.1mm).
Lubricate through air port with ISO VG32 turbine oil before initial use.
Maintain 20mm clearance behind rod end for full stroke operation.
| Property | Property Value |
|---|---|
| sku | B01-SDAJ40X60-30B |
