Airtac B03-4M Explosion-proof Solenoid Valve B03-4M21006A
AirTAC B03-4M Explosion-Proof Solenoid Valve B03-4M21006A
- Model: B03-4M21006A
- Type: 3-position, 4-way closed-center (Explosion-proof pilot-operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.1–0.7 MPa (14.5–101.5 PSI)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 1.2 kg (2.65 lbs) with coil
- Dimensions: 120mm(L) × 50mm(W) × 75mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -25℃ to 80℃ (ambient)
- Power consumption: ≤2.5W (DC), ≤5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Flow coefficient (Cv): 1.8
- Protection rating: IP67 (dust/water resistant)
- Explosion-proof certification: Ex d IIB T4 Gb (IECEx/ATEX compliant)
- Connection type: DIN43650 Form A coil connector
Heavy-duty explosion-proof solenoid valve engineered for hazardous environments requiring ATEX/IECEx compliance. Features brass main body with stainless steel core components and anti-corrosion coating. The dual-chamber explosion-proof design prevents internal spark propagation, with a flame arrestor path ≤40mm. Requires 5μm filtered compressed air or inert gases.
- Petroleum refinery gas control systems
- Coal mine methane ventilation controls
- Paint spray booth pneumatic circuits
- Grain silo dust explosion prevention systems
- Chemical processing plant valve actuators
Critical installation requirements:
Maintain 300mm clearance from potential ignition sources. Use copper alloy tools within explosive atmospheres.
Grounding resistance must be ≤10Ω. Do NOT operate when ambient exceeds temperature class T4 (135℃ surface temp).
| Property | Property Value |
|---|---|
| sku | B03-4M21006A |
