Airtac B03-4M Explosion-proof Solenoid Valve B03-4M21006B
AirTAC B03-4M21006B Explosion-Proof Solenoid Valve Specifications
- Model: B03-4M21006B
- Type: 3/2-way normally closed (direct-acting with explosion-proof housing)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.7 MPa
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 320g ±5% (including coil)
- Dimensions: 80mm(L) × 45mm(W) × 65mm(H)
- Seal material: Fluororubber (FKM) for chemical resistance
- Temperature range: -15℃ to 80℃ (ambient), -5℃ to 60℃ (medium)
- Power consumption: DC: 2.5W, AC: 3.5VA
- Protection rating: IP67 (coil), IP65 (valve body)
- Explosion-proof certification: Ex d IIC T6 Gb (ATEX/IECEx compliant)
- Flow coefficient (Cv): 0.25
- Response time: ≤15ms (at 0.5MPa)
- Interface material: Brass with nickel plating
Heavy-duty explosion-proof solenoid valve featuring flameproof enclosure (Ex d) construction with precision-machined flame paths. Designed for hazardous environments requiring Category 1G/2G explosion protection. Features corrosion-resistant internals and 100% duty cycle operation. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Petrochemical processing equipment
- Pharmaceutical production lines with solvent handling
- Grain silo pneumatic conveying systems
- Paint spray booth automation
- Natural gas processing facilities
- Chemical mixing/stirring systems
Installation requirements:
Must be mounted horizontally with terminal box facing downward.
Maintain minimum 50mm clearance from adjacent surfaces.
Grounding wire connection mandatory - use M4 stainless steel screw
on designated grounding point. Perform seal integrity check every
2000 operational hours.
| Property | Property Value |
|---|---|
| sku | B03-4M21006B |
