Airtac B52-F-M-F Floating Joint Assembly B52-F-M5X080F
$10.66
Regular price
$18.16
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
B52-F-M5X080F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC B52-F-M-F Floating Joint Assembly (B52-F-M5X080F) Specifications
- Full model code: B52-F-M5X080F
- Type: Compensating floating joint with female thread
- Thread specification: M5×0.8 (internal)
- Effective stroke: ±2° angular compensation / ±0.5mm axial compensation
- Max load capacity: 30N (radial), 15N (axial)
- Operating pressure: 0.05-0.7 MPa
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy (AL6061-T6)
- Bearing type: Precision ball bearing (ABEC-3 grade)
- Seal material: NBR rubber with PTFE coating
- Surface hardness: HV 120±5
- Weight: 58g ±2g
- Dimensions: 32mm(Ø) × 42mm(L) × 18mm(Flange thickness)
- Mounting hole spacing: 25mm ±0.1mm (center-to-center)
- Rotation torque: ≤0.15N·m
- Vibration resistance: 10-2000Hz, 5G max
Precision alignment compensator designed for misabsorption in linear motion systems. Features dual-stage sealing with zero-backlash ball bearing structure, optimized for high-cycle automation environments. The nickel-plated steel shaft undergoes salt spray testing for 96hrs protection.
Typical Applications:
- SCARA robot end-effector connections
- Linear guide misalignment compensation
- PCB handling vacuum cup arrays
- Packaging machine pick-and-place units
- Semiconductor wafer transfer systems
Installation protocol:
Apply thread locker (medium strength) on M5 mounting screws.
Maintain 0.3-0.5mm gap between joint flanges during assembly.
Lubricate with ISO VG32 hydraulic oil before initial use.
Matched Components:
- Optimal pairing with AirTAC MMF-15 miniature flange cylinders
- Requires AS-3204 alignment brackets for multi-joint setups
- Compatible with ISO 6432 standard cylinder interfaces
| Property | Property Value |
|---|---|
| sku | B52-F-M5X080F |
