Airtac F-ACQ-I Connector Assembly Kit F-ACQ12I
AirTAC F-ACQ-I Series Fitting Kit: F-ACQ12I Detailed Specifications
- Model Code: F-ACQ12I (Complete Assembly Kit)
- Type: Push-to-Connect Fitting with Pre-assembled Tube
- Thread Standard: BSPP (G) 1/8"
- Tube Compatibility: Ø12mm OD Pneumatic Tubing
- Material: Nickel-plated Brass Body
- Seal Material: HNBR (Hydrogenated Nitrile) O-rings
- Max Working Pressure: 1.0 MPa (145 PSI)
- Temperature Range: -20℃ to 80℃ (Continuous) / 120℃ (Peak)
- Weight: 184g ±2g (Complete Kit)
- Dimensions: 60mm (L) × 30mm (W) × 30mm (H)
- Thread Engagement Depth: 10.5mm (Minimum)
- Insertion Force: ≤35N (Tube Installation)
- Vibration Resistance: 10-55Hz, 1.5mm Amplitude
- Certification: RoHS 2011/65/EU Compliant
Precision-engineered push-lock pneumatic connector with integrated 300mm nylon tubing (standard gray/black). Features anti-vibration teeth and 360° rotatable design for flexible installation. The dual-stage sealing system prevents air leakage under pulsation conditions. Includes built-in tube cutter notch for field adjustments.
- Robotic end-effector pneumatic tooling
- Conveyor system branch line connections
- CNC machine tool air curtain supply
- Semiconductor wafer handling vacuum lines
- Food packaging machine actuator feeds
Installation Protocol:
Cut tube ends square using provided guide, insert fully until "click" engagement.
For high-cycle applications, perform monthly seal lubrication with PAG-based grease (ISO VG 32).
