Airtac F-ACQ-I Connector Assembly Kit F-ACQ32I
AirTAC F-ACQ-I Series Connector Kit F-ACQ32I Technical Details
- Full Model Number: F-ACQ32I (Complete Connector Kit)
- Thread Specification: G1/8 (ISO228-1 Standard)
- Material Composition: Lead-free Brass Body + PPS Composite
- Temperature Tolerance: -20℃ to 80℃ (Dry Air Conditions)
- Pressure Range: 0.3-1.5 MPa (43.5-217.5 PSI)
- Seal Configuration: Dual O-ring (NBR/FKM Optional)
- Surface Treatment: Electroless Nickel Plating (5-8μm)
- Kit Contents:
- 1× Straight Threaded Connector
- 2× EPDM Sealing Washers
- 1× Anti-vibration Nylon Lock Nut
- 1× PTFE Thread Seal Tape (0.1mm×12mm×1m)
- Weight: 78g ±2g (Complete Kit)
- Dimensions: 32mm(Ø) × 48mm(L) (Including Protuberances)
- Torque Specification: 12-15 N·m Installation Torque
- Compatibility: Matches ISO 16030 Standard Ports
High-density pneumatic coupling solution featuring vibration-resistant thread locking technology. The dual-seal design with pressure-adaptive O-rings ensures zero leakage under dynamic load conditions. Nickel plating provides corrosion resistance against water-based lubricants and mild chemicals.
- Pneumatic tool quick-connect systems
- CNC machine air line distribution
- Robotic arm end-effector connections
- Compressed air drying systems
- Food processing pneumatic circuits (FDA-grade seal options available)
Installation Protocol:
Apply 2-3 wraps of included seal tape clockwise. Hand-tighten first,
then apply final torque using a calibrated wrench. Perform pressure
test at 1.25× operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | F-ACQ32I |
