Airtac F-GS Pressure Gauge F-GS4004B
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS Pressure Gauge F-GS4004B Technical Details
- Model: F-GS4004B
- Measurement range: 0-1.6 MPa (0-232 PSI)
- Accuracy class: ±1.6% F.S. (ASME B40.1 Grade B)
- Connection type: G1/4" BSPP female thread (NPT optional)
- Case material: 304 stainless steel with polycarbonate window
- Movement: Bourdon tube mechanism
- Dial diameter: 63mm (2.5")
- Case protection: IP65 dust/water resistance
- Temperature limits:
- Ambient: -20℃ to +60℃
- Medium: -20℃ to +80℃
- Vibration resistance: ≤2.5g @ 10-150Hz
- Liquid filling: Glycerin (98% purity, shock absorption)
- Weight: 310g ±5g (with packaging)
- Dimensions: 63mm(D) × 82mm(H) × 25mm(projection depth)
Industrial-grade pressure gauge featuring a vibration-resistant design with military-grade sealing. The 270° scale rotation allows flexible mounting orientations. The glycerin-filled chamber dampens pointer oscillation in high-pulse environments. Calibrated for both gaseous and non-corrosive liquid media.
- Pneumatic compressor system monitoring
- Hydraulic power unit pressure verification
- CNC machine tool lubrication systems
- Industrial boiler auxiliary pressure indication
- Water treatment plant pump controls
Installation guidelines:
Mount using backup wrench on hexagon base (23mm AF). Avoid direct sunlight exposure.
For pulsating systems, install snubber upstream. Calibrate quarterly under 75% load conditions.
| Property | Property Value |
|---|---|
| sku | F-GS4004B |
| Port Size | PT1/8 |
