Airtac F-GS Pressure Gauge F-GS5010B
2. Precision-engineered dial with clear legibility and multi-unit display options (PSI, bar, MPa, etc.);
3. Flexible mounting configurations supported by modular accessories;
4. Multiple port sizes available (1/8", 1/4") for seamless system integration.
Engineered for industrial automation reliability, the F-GS series combines rapid response dynamics with customizable interface solutions to optimize pneumatic/hydraulic system monitoring.
AirTAC F-GS5010B Pressure Gauge Technical Specifications
- Model: F-GS5010B
- Type: Bourdon tube pressure gauge with liquid-filled dampening
- Measurement range: 0-1.0 MPa (0-10 bar / 0-145 psi)
- Accuracy class: ±2.5% F.S. (EN 837-1 standard)
- Connection size: G1/4" BSPP female thread
- Dial diameter: 63mm (2.5")
- Case material: Stainless steel SS304 with corrosion-resistant coating
- Window: Polycarbonate lens with anti-fog treatment
- Temperature range:
- Ambient: -20℃ to +60℃
- Medium: Max +80℃ for continuous operation
- Vibration resistance: Up to 2.5g @ 10-150Hz
- Protection rating: IP54 (dust protected & water splash resistant)
- Mounting orientation: Radial (bottom entry) or axial (back entry) options
- Weight: 280g ±5% (including fittings)
- Dimensions:
- Body diameter: 63mm
- Overall height: 52mm (without connection)
- Connection length: 18mm thread engagement
- Total length with G1/4" adapter: 82mm
Industrial-grade pressure measurement instrument featuring shock-resistant construction and glycerin-filled chamber for stable needle movement in high-vibration environments. The stainless steel case withstands harsh workshop conditions while the oversized dial with luminescent markings enables quick readings in low-light areas. Includes a brass isolation plug to prevent media contamination.
- Hydraulic power unit pressure monitoring
- Pneumatic compressor system diagnostics
- Injection molding machine pressure verification
- Industrial boiler auxiliary pressure indication
- CNC machine tool lubrication system checks
Installation guidelines:
Mount using proper sealing tape on threads (do not overtighten).
For pulsating media, install a snubber upstream. Avoid direct sunlight
exposure to prevent glycerin discoloration. Calibrate annually using
deadweight tester for critical applications.
| Property | Property Value |
|---|---|
| sku | F-GS5010B |
| Port Size | PT1/4 |
