Airtac F-JCK-AM Clamping Arm F-JCK40AM1L
AirTAC F-JCK-AM Clamping Arm F-JCK40AM1L Technical Specifications
- Model: F-JCK40AM1L
- Clamping force: 350N (at 0.5MPa)
- Stroke: 15±1mm
- Compatible cylinder series: AIRTAC SDA/SUJ/MY1 series
- Material: Anodized aluminum alloy body, stainless steel screws
- Operating temperature: -10℃ to 70℃
- Repeat positioning accuracy: ±0.02mm
- Max operating speed: 500mm/s
- Mounting: M4 threaded holes (4 places)
- Weight: 0.82kg
- Dimensions: 40mm(W) × 40mm(D) × 130mm(H)
- Surface hardness: HV400±50
- Wear resistance: >100,000 cycles (no-load)
Precision-engineered clamping arm with self-locking wedge mechanism, featuring zero-backlash operation and wear compensation. The hardened contact surfaces and dual guide shafts ensure stable gripping force distribution. Requires filtered air supply (40μm) with 0.05-0.7MPa operating pressure range.
- End-of-arm tooling (EOAT) for 6-axis robots
- CNC machine tool fixture positioning
- Automated inspection equipment alignment
- Palletizing system workpiece retention
- Semiconductor wafer handling systems
Maintenance advisory:
Apply lithium soap-based grease every 500,000 cycles. Avoid lateral overload beyond 150N.
Use shim washers when mounting to non-AIRTAC cylinders. Regular guide rod alignment checks recommended.
- AIRTAC SDAS-40D cylinder for vertical applications
- MHP2-16D magnetic sensors for position feedback
- APEC-06-1 pressure regulator for force control
| Property | Property Value |
|---|---|
| sku | F-JCK40AM1L |
| Clamping Arm Model Code | Offset 15mm |
| Bore Diameter | <40mm> |
